80 PLUS® Gold efficiëntie (tot 92,7%)ATX 3.1 PSU met volledige ondersteuning voor PCIe 5.1 GPU’s en GPU’s met 6 2 pin connectorsUitzonderlijk stille 120mm be quiet! ventilatorGeavanceerde stabiliteit en spanningsregulatie dankzij LLC-technologieÉén enorme hoogpresterende 12V-railÉén PCIe 5.1 12V-2×6 600W en 3 PCIe 6 2 connectors voor overgeklokte high-end GPU’s Total power The total power that is needed by the device, or the total power produced by the device. 850 W Peak power This is the maximum power required by the device or peak music power. 900 W AC input voltage The voltage of the AC electricity that is inputted into the product. 100 – 240 V AC input frequency 50/60 Hz Maximum input current (@110V) 12 A Maximum input current (@220V) 6 A Power factor 0.98 Power Factor Correction (PFC) type Active Number of 12V rail(s) 1 Combined power ( 3.3V) 120 W Combined power ( 12V) 850 W Combined power ( 5V) 120 W Combined power (-12V) 3.6 W Combined power ( 5Vsb) 15 W Max output current ( 3.3V) 22 A Max output current ( 12V1) 70.9 A Max output current ( 5V) 22 A Max output current (-12V) 0.3 A Max output current ( 5Vsb) 3 A Hold time 17.34 ms Efficiency 90.5% Power protection features Features that protect the device against power problems e.g. overload. Over current, Over power, Over voltage, Overheating, Short circuit, Surge & inrush protection (SIP), Under voltage Ports & interfaces Motherboard power connector The way in which the motherboard is connected to the power supply. 20 4 pin ATX Motherboard power cable length 55 cm Number of SATA power connectors 6 SATA power cable length 500, 650, 800, 950 mm Peripheral (Molex) power connectors (4-pin) White 4-pinned connector used to connect a peripheral to the power supply. 1 Peripheral (Molex) power cable length 800 mm PCI Express power connectors (6 2 pin) 3 PCI Express power connectors (12-pin) 1 PCI Express power cable length 60 cm CPU power connector (4 4 pin) CPU power cable length 60 cm Cabling type Non-Modular Artikelnummer: 139091 Categorie: Cooling Merk: Be Quiet!
