Ideal Plain 2 Column 32in
$ 90.14
Technical Data Model Specifications Attribute Value Exponent, n 1.2317 Factor, Km 0.92 Height With Legs (mm) 813 Height Without Legs (mm) 748 Bottom Inlet To Floor (mm) 114 Max Section Depth (mm) 213 Mid Section Depth (mm) 187 Output (ΔT50, W) 115 Output (ΔT30, W) 59 Interaxis Distance (mm) 646 Section Length (mm) 76 Internal Volume (L) 2.5 Empty Leg Section Weight (kg) 9.3 Empty Mid Section Weight (kg) 8.37 Casting Origin Hull, England Heating Medium Hydronic, One-pipe steam, Two-pipe steam Construction Types Threaded nipples Connection Options BBOE, TBOE, TBSE Sizes Available SKU N Secs Length (L, mm) Output (∆T50, Watts) Output (∆T30, Watts) Delivery pieces Price from ORC-NRC-IP-2C32-5 5 410 575 295 1 £0.00 8847 ORC-NRC-IP-2C32-6 6 486 690 354 1 £0.00 8847 ORC-NRC-IP-2C32-7 7 562 805 413 1 £0.00 8847 ORC-NRC-IP-2C32-8 8 638 920 472 1 £0.00 8847 ORC-NRC-IP-2C32-9 9 714 1035 531 1 £0.00 8847 ORC-NRC-IP-2C32-10 10 790 1150 590 1 £0.00 8847 ORC-NRC-IP-2C32-11 11 866 1265 649 1 £0.00 8847 ORC-NRC-IP-2C32-18 18 1398 2070 1062 1 £0.00 8847 Related products Duchess 1 Column 39in From: £0.00 Princess Scroll 2 Column 36in From: £0.00 Duchess 1 Column 36in From: £0.00 Duchess 3 Column 36in From: £0.00
