Ideal Plain 1 Column 32in
$ 92.62
Technical Data Model Specifications Attribute Value Exponent, n 1.25 Factor, Km 0.72 Height With Legs (mm) 813 Height Without Legs (mm) 749 Bottom Inlet To Floor (mm) 114 Max Section Depth (mm) 140 Mid Section Depth (mm) 114 Output (ΔT50, W) 96 Output (ΔT30, W) 49 Interaxis Distance (mm) 646 Section Length (mm) 76 Internal Volume (L) 1.2 Empty Leg Section Weight (kg) 8.2 Empty Mid Section Weight (kg) 7.4 Casting Origin Hull, England Heating Medium Hydronic, One-pipe steam, Two-pipe steam Construction Types Threaded nipples Connection Options BBOE, TBOE, TBSE Sizes Available SKU N Secs Length (L, mm) Output (∆T50, Watts) Output (∆T30, Watts) Delivery pieces Price from ORC-NRC-IP-1C32-4 4 334 384 196 1 £0.00 8806 ORC-NRC-IP-1C32-5 5 410 480 245 1 £0.00 8806 ORC-NRC-IP-1C32-6 6 486 576 294 1 £0.00 8806 ORC-NRC-IP-1C32-7 7 562 672 343 1 £0.00 8806 ORC-NRC-IP-1C32-8 8 638 768 392 1 £0.00 8806 ORC-NRC-IP-1C32-9 9 714 864 441 1 £0.00 8806 ORC-NRC-IP-1C32-10 10 790 960 490 1 £0.00 8806 ORC-NRC-IP-1C32-12 12 942 1152 588 1 £0.00 8806 ORC-NRC-IP-1C32-17 17 1322 1632 833 1 £0.00 8806 Related products Princess Window 13in From: £0.00 Princess 2 Column 30in From: £0.00 Duchess Scroll 1 Column 24in From: £0.00 Ideal Plain 1 Column 23in From: £0.00
